FortiGate 100E

Interfaces and Modules

Hardware Accelerated GE RJ45 Ports

12

Hardware Accelerated GE RJ45 Management/ HA/ DMZ Ports

1 / 2 / 1

Hardware Accelerated GE SFP Slots

4

Hardware Accelerated 10 GE SFP+ FortiLink Slots (default)

2

GE RJ45 WAN Ports

2

GE RJ45 or SFP Shared Ports *

4

USB Port

1

Console Port

1

Onboard Storage

0

Trusted Platform Module (TPM)

—

Bluetooth Low Energy (BLE)

—

Signed Firmware Hardware Switch

—

Included Transceivers

0

System Performance — Enterprise Traffic Mix

IPS Throughput 2

2.6 Gbps

NGFW Throughput 2, 4

1.6 Gbps

Threat Protection Throughput 2, 5

1 Gbps

System Performance and Capacity

IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)

20 / 18 / 10 Gbps

Firewall Latency (64 byte, UDP)

4.97 μs

Firewall Throughput (Packet per Second)

15 Mpps

Concurrent Sessions (TCP)

1.5 Million

New Sessions/Second (TCP)

56 000

Firewall Policies

10 000

IPsec VPN Throughput (512 byte) 1

11.5 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

2000

Client-to-Gateway IPsec VPN Tunnels

16 000

SSL-VPN Throughput

1 Gbps

Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)

500

SSL Inspection Throughput(IPS, avg. HTTPS) 3

1 Gbps

SSL Inspection CPS (IPS, avg. HTTPS) 3

1800

SSL Inspection Concurrent Session(IPS, avg. HTTPS) 3

135 000

Application Control Throughput(HTTP 64K) 2

2.2 Gbps

CAPWAP Throughput (HTTP 64K)

15 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of FortiSwitches Supported

32

Maximum Number of FortiAPs (Total / Tunnel)

128 / 64

Maximum Number of FortiTokens

5000

High Availability Configurations

Active-Active, Active-Passive, Clustering
