FortiGate 400G
|
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Slots |
4 |
|
Hardware Accelerated 10 GE SFP+ / GE SFP Slots |
4 |
|
Hardware Accelerated GE SFP Slots |
16 |
|
Hardware Accelerated 5GE RJ45 Slots |
8 |
|
2.5 GE / GE HA Port |
1 |
|
GE Management Port |
1 |
|
USB Ports (Client / Server) |
2 |
|
Console Port |
1 |
|
Trusted Platform Module (TPM) |
Yes |
|
Signed Firmware Hardware Switch |
Yes |
|
FortiSentry |
Yes |
|
Included Transceivers |
2x SFP SX |
|
IPS Throughput 2 |
25 Gbps |
|
NGFW Throughput 2, 4 |
14 Gbps |
|
Threat Protection Throughput 2, 5 |
13 Gbps |
|
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
164 / 164 / 145 Gbps |
|
IPv6 Firewall Throughput(1518 / 512 / 86 byte, UDP) |
164 / 164 / 145 Gbps |
|
Firewall Latency (64 byte, UDP) |
2.51 μs |
|
Firewall Throughput (Packet per Second) |
217.5 Mpps |
|
Concurrent Sessions (TCP) |
28 Million |
|
New Sessions/Second (TCP) |
580000 |
|
Firewall Policies |
10000 |
|
IPsec VPN Throughput (512 byte)1 |
55 Gbps |
|
Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
|
Client-to-Gateway IPsec VPN Tunnels |
50000 |
|
SSL-VPN Throughput |
6.1 Gbps |
|
Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) |
5000 |
|
SSL Inspection Throughput(IPS, avg HTTPS)3 |
11.5 Gbps |
|
SSL Inspection CPS (IPS, avg. HTTPS)3 |
9700 |
|
SSL Inspection Concurrent Session(IPS, avg HTTPS)3 |
3 Million |
|
Application Control Throughput (HTTP 64K)2 |
50 Gbps |
|
CAPWAP Throughput (HTTP 64K) |
131 Gbps |
|
Virtual Domains (Default / Maximum) |
10 / 25 |
|
Maximum Number of FortiSwitchesSupported |
96 |
|
Maximum Number of FortiAPs(Total / Tunnel) |
512 / 256 |
|
Maximum Number of FortiTokens |
5000 |
|
High Availability Configurations |
Active-Active, Active-Passive, Clustering |
